Type of Microbolometer | Uncooled Microbolometer |
Frame Rate, Hz | 50 |
Microbolometer Resolution, pixels | 320 x 240 |
Spectral Sensitivity, µm | 8-14 |
Pixel Pitch, µm | 12 |
Display Type | AMOLED |
Display Resolution, pix. | 1024 x 768 |
Integrated video recorder | Yes |
Micro USB Socket | Power/Data |
Operating modes | Rocks, Forest, Identification |
Defective Pixel Repair Option | Yes |
Integrated Wi-Fi | Yes |
Stream Vision support | Yes |
Magnification | 5.5 - 22 |
Digital Zoom | 2x / 4x |
Lens Focus, mm | 50 |
Relative aperture, D/f' | 1:1.2 |
Field of View, degrees | 4.4 |
Field of view, m@100m | 7.7 |
Field of view, ft@100yd | 23.1 |
Minimum focusing distance, ft/m | 16' (5m) |
Eye Relief | 2 / 50 |
Diopter Adjustment | -4 / +3 |
Focusing Type of Distance | Objective |
Range of Detection | 2500 / 2300 |
Power Supply | 3.0 - 4.2 |
Battery Type | B-Pack mini (18650 Li-Ion) |
External Power Supply | 5V - USB |
Click value (MOA) | 0.25 |
Elevation Range of Adjustment | 48 |
Windage Range of Adjustment | 48 |
Lens Material | Germanium |
Type of Mount for Attachment of Additional Accessories | Weaver/picatinny rail |
Operating Temperature | -13 to 122 / -25 to +50 |
Reticle, Type | 10+ variable electronic reticles |
Waterproof | Yes |
Calibration | Manual, Automatic, Semi-automatic |
Level of Protection (acc. to IEC 60529) | IP67 100% dustproof and submergible to 1m for 1 hour |
Recoil Rating | .375 H&H |
Length | 15.8" (402mm) |
Width | 3.1" (78mm) |
Height | 2.5" (64mm) |
Battery life, (with video out off), hours | 5+ |
Body Material | Aluminum |
Weight | 31.75 oz |
Diameter, Lens, mm | 42 |
